Equipments
Equipment Details
EMERSON DCS
M Series- MQ, Analog Input : 16Ch,4-20mA, HART
Analog Output : 16Ch,4-20mA, HART
Digital Input : 32Ch, 24V dc
Digital Output : 32 Ch, 24V dc
Communication : Serial
Smart wireless gateway 30V dc max 3Watt
Quantity: 01
PLC (Siemens S7-1200)
SIMATIC S7-1200,
CPU 1214C, Compact CPU, DC/DC/DC,
On-board I/O: 14 DI 24V DC; 10 DO 24V DC; 2 AI 0-10V DC,
Power supply: DC 20.4-28.8V DC,
Program/data memory 100 KB
Quantity: 01
PLC (Siemens S7-300)
SIMATIC S7-300,
CPU 314C-2PN/DP Compact CPU with 192 KB work memory, 24 DI/16 DO, 4 AI, 2 AO, 1 Pt100, 4 high-speed counters (60 kHz), 1st interface MPI/DP 12 Mbit/s, 2nd interface Ethernet PROFINET, with 2-port switch, Integr. power supply 24 V DC, Front connector (2x 40-pole) and Micro Memory Card required
Quantity: 01
PLC (Allen Bradely MicroLogix 1400)
7 expansion I/O modules for a maximum of 256 discrete I/O Up to 6 embedded 100 kHz highspeed counters (on controllers with dc inputs) 2 Serial ports with DF1/ DH485/ Modbus RTU/DNP3/ASCII protocol support Ethernet port provides you with EtherNet/IP, DNP3 over IP and Modbus TCP/IP protocol support as well as web server and email capabilities Built-in LCD with backlight allows you to view controller and I/O status, and provides a simple interface for messages, bit / integer monitoring and manipulation
Quantity: 01
L&T Automation Kit
PLC : XLB Series, Digital I/O module, Analog I/O module
HMI : 7”
SCADA : iVision Max ver 11 preinstalled.
Energy Meter with MODBUS RTU interface module
Quantity: 01
OSI PI
SCADA Historian
Quantity: 01
Ivision Max SCADA
L & T Make SCADA application ver 3.12,
Tags/ points : 5000points,
Scripting : VB Scripting.
Quantity: 01
RTU SCADA Pack 334E
CPU: 32-bit ARM7 microcontroller, 32 MHz clock, integrated watchdog timer
Memory 16MB FLASH ROM, 4MB CMOS RAM, 4kB EEPROM
Non-Volalite RAM CMOS SRAM for 2 years
Event Logging Capacity 20,000 events
Maximum Database Points 1,000 typical
Quantity: 01
RTU (KalkiTech SYNC 2101)
Enabled with smart grid protocols IEC 60870-101/104, DNP3.0,
Modbus and IEC 61850
Stores last 10,000 events
Multi-master communication capability (many-to-many protocol conversion capability)
Local/Remote communication over serial and Ethernet port
Time synchronization using IEC60870/DNP3/SNTP
Device management using SNMP/webserver
Time stamping resolution of 1 millisecond
Device and communication redundancy supported
Quantity: 03
Tofino Xenon Security Appliance
Interface: 2 x 100BASE-TX, 1 x 100BASE-FX, 1 x 100BASE-TX, or 2 x 100BASE-FX
Power 12 to 48 V DC, 24 V AC redundant power supply 5-7 Watts(dependent on device variant)
Dual redundant power inputs; 24-12AWG screw cage terminals
Quantity: 03
DC Smart Energy Meter
EVERON make (Model-EV-DSL-02W)
Capacity: 900V,40A
Quantity: 02
Palo Alto Firewall
PA-3020 Series
2 Gbps firewall throughput (App-ID enabled), 1 Gbps Threat Prevention throughput , 500 Mbps IPsec VPN throughput, 250,000 max sessions, 50,000 new sessions per second, 3000 IPsec VPN tunnels/tunnel interfaces, 1,000 SSL VPN users, 10 virtual routers, 1/6 virtual systems (base/max1), 40 security zones, 2,500 max number of policies
Quantity: 01
Dell Server
POWEREDGE R740
Up to two Intel® Xeon® Scalable processors, up to 28 cores per processor,
24 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to 2666MT/s, 3TB max Up to 12 NVDIMM, 192 GB Max, Supports registered ECC DDR4 DIMMs only, Internal controllers: PERC H330, H730p, H740p, Software RAID (SWRAID) S140 Boot Optimized Storage Subsystem: HWRAID 2 x M.2 SSDs 120GB, 240 GB. External PERC (RAID): H840 12Gbps SAS HBAs (non-RAID): External- 12 Gbps SAS HBA (non-RAID), Internal- HBA330 (non-RAID).
Quantity: 01
PSSE
High-performance transmission planning and analysis software
Quantity: 01
SINCAL
Simulation software for the analysis and planning of power networks at all voltage levels
Quantity: 01
Phasor Measurement Unit (PMU)
Vizimax,
Quantity: 03
OPAL-RT
OP5600, Hardware-in-the-Loop (HIL) testing equipment
Quantity: 01
NVIDIA TITANXP
3840 NVIDIA, CUDA®Cores
Quantity: 01
Industrial IOT Panel
L&T Infotech Make
Quantity: 01
MPLS Routers
CISCO make
Quantity: 05
Ruggedized Switches
CISCO make
Quantity: 05
PoE switches
CISCO make
Quantity: 02
Wireless Acess Points Internal
CISCO make
Quantity: 02
DC switch for Connecting servers
CISCO make
Quantity: 01
Servers with Virtualization
CISCO make
Quantity: 03
Firewall
CISCO make
Quantity: 01
Behavioral analysis solution
CISCO make
Quantity: 01
DNS Security solution for 10 endpoints
CISCO make
Quantity: 01
Advanced malware prevention solution for 10 endpoints.
CISCO make
Quantity: 01
IP Phones
CISCO make
Quantity: 01
Call manager for VoIP and video communications
CISCO
Quantity: 01
Video endpoints (55”)
CISCO
Quantity: 01
Mixed Domain Oscilloscope
Tetronix
Quantity: 01
Thermal Imager
Fluke
Quantity: 01
3 phase power quality analyzer
Fluke
Quantity: 01
Isolated Four Channel Digital Scope Corder
Yokogava
Quantity: 01
3 & 1⁄2 Handheld Digital Multi meter, Tables and Data Processing unit Plus additional monitor
Fluke
Quantity: 01
Power Supply: 0-32 V: 5 Amp DC
Prodigit
Quantity: 03
Digital Precision Multimeter: 5.5 digits
Tektroni
Quantity: 01
Multilevel Inverter Panel
5 Level IGBT Power Stack (2x3 H Bridges, 120V/25A, with built in DC Capacitors, Driver Cards, Heat Sink, Fuses & 3 Phase Diode Bridge)
Quantity: 01
Matrix Converter and 5.5 kW VFD Panel
25 KVA, 50 Hz, 415 V AC input voltage, 415 V DC output voltage, 20kHz switching frequency (L&T)
Inverter Model LTVF-Fx2000, 5.5kW HD (L&T)
Stability and Synchrophasor Measurement System (GE Multilin)
Quantity: 01
Different Types of Power Stacks
Three ph Diode Bridge and Invertor (4 Legs) with driver cards: 415 V AC input voltage, 600 V DC output voltage, 415 V AC output voltage, 30 A AC output current, 15 kHz switching frequency (L&T)
3 ph AFE and Invertor with driver cards: 3 ph front end rectifier and IGBT based 3 ph inverter, 415 V, 50 Hz AC input voltage, 720 V DC, 415 V AC output voltage, 30 A output AC current (L&T)
Quantity: 01
Three Phase Auto-transformer with
Overcurrent Protection, Primary voltage: 415V, Secondary voltage: 0 to 415V, Output Current: 10 Amp
Quantity: 01
Variable DC Supply Panel
3 ph, 415 V AC input voltage, 560 V DC Max, 60 V DC Min
3 ph, 12kVA, 330V/415 V transformer with Switch fuse unit on both side
Quantity: 01
NVIDIA DGX-1 (INSTRUMENT FOR AI RESEARCH)
CPU Dual 20-Core Intel Xeon E5-2698 v4 2.2 GHz
GPUs : 8X Tesla V100
Performance (GPU FP16) : 1 petaFLOPS
GPU Memory : 128 GB total system
NVIDIA CUDA® Cores : 40,960
NVIDIA Tensor Cores (on V100 based systems) : 5,120
Storage 4X 1.92 TB SSD RAID 0
Network Dual 10 GbE, 4 IB EDR
Software Ubuntu Linux Host OS
Quantity: 01
K-Box
Intel® AtomTM E3845 4x 1.91 GHz Phoenix SecureCoreTM
DDR3L, with ECC 4 GByte Soldered
1x RS232, 1x RS485 2x USB 2.0 1x HDMI 2x GbE, IEEE1588 support
Quantity: 01
Beaglebone black
512MB DDR3 RAM
4GB 8-bit eMMC on-board flash storage
3D graphics accelerator
2x PRU 32-bit microcontrollers
65 Digital pins(3.3v)
Analog pins (1.8v)
Processor speed- 1GHz
Quantity: 03
Internet embedded controller ( I-7000 bus converter)
Asynchronous half duplex 2-wire RS-485 NETWORK
Max. distance without repeater =4000feet(1.2km)
power- 10v to 30v DC
Protocol: RS-422/485
Quantity: 05
MOXA UC-7124-ce
Cirrus Logic EP9302 ARM9 32-bit 200 MHz processor
On-board 32 MB RAM, 16 MB flash disk
2 or 4 software-selectable RS-232/422/485 serial ports
50 bps to 921.6 kbps baudrate (nonstandard baudrates supported)
Dual 10/100 Mbps Ethernet for network redundancy
SD socket for storage expansion supported
Built-in real-time clock (RTC), buzzer, watchdog timer (WDT)
Quantity: 01
MOXA MGate MB3480
Supports Auto-Device Routing for easy configuration
Supports route by TCP port or IP address for flexible deployment
Convert between Modbus TCP and Modbus RTU/ASCII
1 Ethernet port and 1, 2, or 4 RS-232/422/485 ports
16 simultaneous TCP masters with up to 32 simultaneous requests per master
Quantity: 01
MOXA IA240
MOXA ART 32-bit ARM9 industrial processor
64 MB RAM, 16 MB flash onboard
4 RS-232/422/485 serial ports
4 digital input and 4 digital output channels (TTL signal)
Dual 10/100 Mbps Ethernet for network redundancy
Ready-to-run Linux Kernel 2.6 platform
OS (pre-installed): Embedded Linux
DRAM: 64 MB onboard
Flash: 16 MB onboard
Quantity: 01
MOXA MGate 4101-MB-PBS
Protocol conversion between Modbus and PROFIBUS
Input Voltage: 12 to 48 VDC
Data Rate: 9600 bps, 19.2, 93.75, 187.5, 500 kbps, 1.5, 3, 6 and 12 Mbps
Protocol: Modbus ASCII/RTU, Master/Slave
Quantity: 01
Intel Edison board
4 GB eMMC flash on board, Wi-Fi, Bluetooth and USB controllers.
70-pin dense connector (Hirose DF40) with USB, SD, UARTs, GPIOs
Quantity: 02
NVIDIA JETSON TX2
GPU: NVIDIA PascalTM, 256 CUDA cores
CPU: HMP Dual Denver 2/2 MB L2 + Quad ARM® A57/2 MB L2
MEMORY: 8 GB 128 bit LPDDR4 59.7 GB/s
DATA STORAGE: 32 GB eMMC, SDIO, SATA
Quantity: 04
NVIDIA TITANXP
3840 NVIDIA CUDA® Cores
1582 Boost Clock (MHz), 11.4 Gbps Memory Speed , 12 GB GDDR5X
Standard Memory Configuration, 384-bit Memory Interface Width
Windows 7-101, Linux, FreeBSDx86, OS Certification, DP 1.43,
Quantity: 01
KINTEX (7) FPGA Embedded Kit
Logic Cells 326,080
DSP Slices 840
Memory 16,020
GTX Transceivers 16
I/O Pins 500
Quantity: 02
ZYNQ SOC all Programmable Embedded Kit
Logic Cells (K) 85
Block RAM (Mb) 4.9
DSP Slices 220
Maximum I/O Pins 200
Quantity: 02
Raspberry Pi
Version 3.0
Quantity: 07
Arduino Yun
microcontroller board based on the ATmega32u4 and the Atheros AR9331.Built-in Ethernet and WiFi support, a USB-A port, micro-SD card slot, 20 digital input/output pins (of which 7 can be used as PWM outputs and 12 as analog inputs), a 16 MHz crystal oscillator, a micro USB connection, an ICSP header, and a 3 reset buttons.
Quantity: 01
Arduino Mega
54 digital input/output pins (of which 14 can be used as PWM outputs), 16 analog inputs, 4 UARTs (hardware serial ports), a 16 MHz crystal oscillator, a USB connection, a power jack, an ICSP header, and a reset button
Quantity: 04
FPGA (Papila Platform)
Fully Assembled with a Xilinx XC3S500E and 4Mbit SPI Flash Memory
Two-Channel USB Connection for JTAG and Serial Communications
Four Independent Power Rails at 5V, 3.3V, 2.5V, and 1.2V
Power Supplied by a Power Connector or USB
Input Voltage (recommended): 6.5-15V, 48 I/O lines!
Quantity: 03
LORA B DRAGINO Module Node(Arduino)
Frequency Band: 868 MHZ/433 MHZ/915 MHZ(Pre-configure in factory)
Low power consumption, Compatible with Arduino Leonardo, Uno, Mega,Due etc.
FSK, GFSK, MSK, GMSK, LoRaTMand OOK modulation
Preamble detection,Baud rate configurable
Support DGPS, SBAS(WAAS/EGNOS/MSAS/GAGAN)
Quantity: 01
LORA B DRAGINO Module Node(for Rpi)
Frequency Band: 868 MHZ/433 MHZ/915 MHZ(Pre-configure in factory)
Low power consumption, Compatible with Raspberry Pi 2 Model B/Raspberry Pi 3.
SK, GFSK, MSK, GMSK, LoRaTM and OOK modulation
Quantity: 01
IC 880 LORA WAN Concentrator
(Gateway) with antenna and adapter, support of multiple channels and spreading factors in parallel
